Expert Review, Technical Specifications & Market Analysis
| Feature | Specifications |
|---|---|
| Overall Length | 63' 8" |
| Beam | 16' 10" |
| Draft | 4' 0" |
| Displacement | 88,926 lbs |
| Engines | 2 x Volvo Penta D13-900 (900 hp); optional 2 x Volvo Penta D13-1000 or 2 x MAN V8-1200 |
| Fuel Capacity | 898 gal |
| Water Capacity | 185 gal |
| Cabins / Heads | 3/4 Cabins + 1 Crew / 3 Heads |
| Max Speed | 31 knots |
| Cruise Speed | 23 knots |
Source: Spec & Photos courtesy of Galeon. Specs verified by Tony Smith, USCG 100 Ton Master, on August 24, 2026.
Terrace Mode folds the port aft balcony down and opens the full-beam master cabin straight onto a water-level terrace - 16' 10" of beam becomes 27' 2". Both Terrace Mode and Beach Mode are standard, not options.
Part of the Galeon FLY series — see how owners step up through the lineup.
I look at a lot of 60-to-65-foot flybridge boats and most of them are arguing about the same things - saloon volume, hardtop, how big the sunpad is. The Galeon 620 is arguing about something else, and it is the reason I would put it on a client's list. The port aft balcony folds down and it opens off the master cabin. Not off the cockpit, not off the saloon - off the owner's suite, at the water. And it is standard equipment, with Beach Mode standard on the other side too. Sixteen feet ten of beam becomes twenty-seven feet two. If you spend your summer at anchor, that is not a feature, that is the boat.
Here is the part I want you to be careful with. Air conditioning is an option on this boat. The generator that comes standard is a 17.5 kW Onan and it will not run air conditioning - Galeon says as much itself. The 27 kW unit is another option again. Those three decisions travel together and they happen at the order desk, not at the dock. Same for the engines - Volvo Penta D13-900s are standard, D13-1000s and MAN V8-1200s are on the options list. I want your engine ceiling written on your build contract rather than read off a website.
What I would do before signing is simple. Ask for observed fuel burn at cruise, in writing, because 31 knots and 23 knots are the builder's own numbers and nobody has tested them for you. Ask for the rigged, loaded weight, because the 88,926 lbs on the sheet is a light-craft number with base engines. And go stand on that port terrace with the balcony down, because that is the whole thesis of the 620 and it is the one thing no spec sheet is going to settle for you.
Video courtesy of Galeon.
Photos courtesy of Galeon.
The Galeon 620 FLY is a 63' 8" flybridge motoryacht built on what Galeon calls a wide U-shaped hull, and the reason to look at it ahead of the obvious European rivals is one piece of standard equipment. Terrace Mode is a pair of hydraulically foldable aft balconies, and the port one opens directly off the full-beam master cabin - at water level, aft and to port. Beach Mode sits alongside it, also standard: a hydraulically opening aft balcony on the starboard side with a sliding aft side window and a bar that converts inside the cockpit. Neither is a line item you add later. On a boat this size that is unusual, and it is the whole argument for the model.
Beam is 16' 10" closed. With the balconies down it reaches a maximum of 27' 2", which is the number that matters for your slip and for how the boat actually gets used at anchor. Draft is 4' 0". Fuel is 898 gallons across two tanks, fresh water is 185 gallons, the grey tank holds 79 gallons and the black tank 54. Displacement in light craft condition is 88,926 lbs with maximum load rated at 12,169 lbs. Galeon certifies the boat to CE Category B.
Power comes with the engine builder named. The standard package is twin Volvo Penta D13-900s at 900 hp each with a 7" digital display. The options list adds twin Volvo Penta D13-1000s and twin MAN V8-1200s, the latter bringing a three-station joystick system with it. Maximum speed is 31 knots. Three cabins with three bathrooms is the standard layout; four cabins is optional, as is a skipper cabin aft, and the flybridge runs roughly 590 square feet of deck. Galeon builds the boat in Poland, where the yard has been family-owned since 1982.
The 620 will run to 31 knots and cruise at 23 on Galeon's own figures. Treat both as the builder's numbers rather than a tested result, and plan to confirm them at sea trial.
The engine choice is where the 620 gets interesting. Twin Volvo Penta D13-900s are standard, with twin Volvo Penta D13-1000s and twin MAN V8-1200s on the options list. The top rating is quoted both as 2 x 1,200 hp and as 2 x 1,000 hp, so confirm the ceiling on your build sheet rather than assume it - 200 hp a side moves both the price and the resale story.
The rest of the running gear is worth knowing for what is and is not included. Zipwake interceptor trim tabs with autotrim and autolist are standard; Humphree interceptors with coordinated turn control are an upgrade. A bow thruster with joystick is standard, a stern thruster is not, and the MAN joystick package requires proportional thrusters at both ends. The hydraulic bathing platform is rated at 1,543 lbs of lift, which sets your tender size before anything else does.
Two things to plan around. Ask for observed burn at cruise in writing and do the range arithmetic off 898 gallons yourself. And the 88,926 lb displacement is a light-craft figure with base engines - get a rigged, loaded weight before you commit a lift.
The full-beam master suite is the centre of this boat and the terrace is the reason. Terrace Mode drops a pair of hydraulic aft balconies: the port one opens straight off the owner's cabin at water level, while the starboard side stays clear to moor a tender or a jet ski. Aft and to port, off the master - and it is standard equipment rather than a line item you add later. Very little else at this size does that at all, let alone without an option box.
The standard layout is three cabins with three bathrooms and the galley aft; four cabins is optional, as is moving the galley to the bow. A skipper cabin aft is a separate option, and if you take it, air conditioning for that cabin is another. The saloon has floor-to-ceiling glazing, a side pantograph door beside the helm for single-handed docking, and an optional electrically opening port-side window. The flybridge carries a U-shaped sofa, a bar with grill and sink, companion seating beside the helm and a laminated hardtop with a solid roof as standard.
Two things deserve reading twice before you configure. The standard generator is a 17.5 kW Onan and it will not run air conditioning - the 27 kW unit is optional, and so is the air conditioning itself, at 87,000 BTU or 127,000 BTU in tropical specification. The standard water heater holds 21 gallons. Finishes run to a set of five Mediterranean design packages - Ocean, Amber, Terra, Pearl and Ivory - over a long list of individual veneers. A Seakeeper 10, a watermaker at roughly 26 gallons an hour, a dishwasher, a freezer, a wine cooler and a washer-dryer are all options rather than standard.
Within Galeon's own flybridge range the 620 FLY sits above the 560 FLY and below the 640 FLY, and the gaps are unusual. The 640 is only about four and a half feet longer but carries 991 gallons of fuel against 898, and its Beach Mode balconies open to 24' 3" where the 620's open to 27' 2". So the smaller boat has the wider footprint at anchor. If your reason for buying a Galeon is the balconies, the 620 is not automatically the compromise choice.
Against the wider 60-to-65-foot flybridge market - the Italian and British builders who own this size class - the 620's argument is specific rather than general. Those boats will match it on saloon volume, on brand recognition and in most cases on published performance data. What they do not do is fold the owner's cabin open onto a water-level terrace as standard equipment. If you spend most of your season at anchor rather than under way, that is a real difference in how the boat is used, and it is measurable: 16' 10" becomes 27' 2".
Where the 620 asks more of a buyer is paperwork. The figures that go on a slip application, an insurance policy or a travelift sling should come off your build contract, with the engine ceiling named and rated on the same page - and budget a proper sea trial to verify the performance for yourself.
One practical note before you get to layouts. Air conditioning is an option on this boat, the standard generator will not run it, and the 27 kW generator is a separate line again. Those three items move together, they move early in the build, and they are not the kind of thing you retrofit at a dock.
The 620 FLY fits the owner whose season happens at anchor. Terrace Mode and Beach Mode together turn a 16' 10" boat into a 27' 2" one, with the master cabin opening onto the port terrace at water level, a bar that converts inside the cockpit, and the starboard side left clear to moor a tender or a jet ski. That is a genuinely different way to use a 63-footer, and if it is not how you use a boat, most of what you are paying for here is idle.
It fits a family that wants the third and fourth cabins to be real. Three cabins and three bathrooms is standard, four cabins is optional, and the skipper cabin aft is a further option on top of that. The layout is flexible in the galley too - aft as standard, forward if you prefer, with a galley island available only with the aft arrangement. Sixteen is the hull's rated accommodation.
It fits an owner-operator. A bow thruster with joystick is standard, the side pantograph door puts the skipper on the side deck in two steps, and the full-control packages on both engine options add cruise control and single-lever operation. Add the stern thruster and proportional upgrade and it is a very manageable boat for a couple.
It is the wrong boat if you need a tested performance table before you sign. You get a maximum speed and a cruise speed, and you will be measuring the rest yourself at sea trial. It is also the wrong boat if you assume air conditioning is standard equipment at this size; on the 620 it is an option, and so is the generator that can actually run it.
No. The standard 17.5 kW Onan generator is not sufficient for air conditioning, and Galeon says so itself. Air conditioning is not standard either - it is an option, an 87,000 BTU chilled-water system with heating inverter, with a 127,000 BTU tropical version listed beside it. A larger 27 kW generator is a third, separate option.
Those are three separate lines that need deciding together at the order desk. If you intend to lie at anchor in Florida or the Bahamas with the boat cool, you are buying the air conditioning, quite possibly the tropical version, and the bigger generator - none of which is in the standard boat. Price all three together rather than one at a time. Worth pricing in the same conversation, because they are the ones owners tend to add later at greater cost: the Seakeeper 10, the watermaker at roughly 26 gallons an hour, a stern thruster with joystick, and the upgrade from the standard Zipwake interceptors to Humphree with coordinated turn control.
Aft. There are two separate systems and both are standard. Terrace Mode drops a pair of hydraulically foldable aft balconies, with the port one giving access directly to the master cabin and the starboard side left as space to moor the tender or jet ski. Beach Mode opens a hydraulic aft balcony on the starboard side, with a sliding openable aft side window and a convertible bar area inside the cockpit.
So the terrace is off the master's port side, at the stern, at water level. The published payoff is a beam of 16' 10" closed and 27' 2" with the balconies down. Do not go to a viewing expecting a balcony at the bow.
Twin Volvo Penta D13-900s are standard, and the options list adds twin Volvo Penta D13-1000s and twin MAN V8-1200s. The top rating is quoted two ways, though - 2 x 1,200 hp and 2 x 1,000 hp - so the ceiling is worth confirming on the build sheet for the hull you are buying. 200 hp a side moves both the price and the resale story.
Raise one dependency in the same conversation: the MAN joystick option requires bow and stern thrusters with the proportional upgrade, so the big engines pull other line items along behind them.
23 knots, with 31 knots flat out - Galeon's own two figures for the boat.
Read both as builder's figures rather than test results. With 898 gallons aboard, ask for observed burn at 23 knots in writing before you build a range estimate on it.
